Spiral Staircase Bury

Our model 71 spiral staircase  is a bespoke model available in a variety of timbers and diameters.  Whilst we offer a range of economically priced spiral staircases but sometimes a premium product offer the  perfect solution.  Not only does a custom made option offer more material and finish options, the geometry can be adjusted to suit the application.

This model was supplied and fitted within a circular turret with a bespoke platform and vertical stainless steel spindles.  1800mm diameter in total with Oak treads and handrail.  This model had stainless steel riser bars to reduce the gap to comply with the 100mm gap rule.

Spiral Staircase Bury St Edmounds- Technical Specifications

Floor to floor height 2742mm
Risers 14 @ 195.8mm
Spiral Diameter 1800mm
Clear Tread Width 800mm
Tread Type 50mm Oak
Balustrade Type 20mm vertical stainless steel spindles
Handrail 50mm Ø Oak
Centre Column 146mm Ø
Finish of Steel Brushed Stainless Steel
Additional stainless steel riser bars

Contact us about project Spiral Staircase Bury St Edmounds- Model 71
