Spiral Staircase Edinburgh – Model 70

This spiral staircase was supplied to a client involved in extending her barn near Edinburgh.

A spiral staircase was required to access a small mezzanine deck which served as a reading gallery overlooking the new kitchen.

Gallery Spiral Staircase

Given there were many original oak beams on view, and that the doors and floor were to be oak, the spiral staircase had to match. The Model 70 spiral was specified which combine solid timber treads, centre column, spindles and handrail. The treads themselves cantilever directly from the centre column without requiring any bulky steel tread supports.

On this particular model we continued the handrail and spindles along the balcony upstairs to complete the spiral.

If you would like a price for this case study ‘spiral staircase Edinburgh’, please fill in the form below.

Download Project Case Study

Staircase Case Sudy

Spiral Staircase Edinburgh - Model 70- Technical Specifications

Floor to floor height 2564mm
Risers 12 @ 213.67mm
Spiral Diameter 1400mm
Newel Posts
60 x 60mm Oak
Tread Type 40mm Oak
Balustrade Type 20mm Ø OakSpindles
Handrail 70 x 40mm Oak handrail in one piece
Centre Column Oak barrels
Finish of timber Matt varnished
Additional 2m matching landing balustrade

Complete Stair Systems

Comment on Spiral Staircase Edinburgh  from Complete Stair Systems

Ed Butler

Project Manager

"The model 70 was the perfect spiral staircase for this application. A mix of old and new was required and the timber had to match the existing oak on display"
