12^th November 2012

Spiral Staircase Dorset

Stunning model 71 spiral staircase pictures from a customer in Poole, Dorset!

The model 71 spiral staircase is our most popular bespoke spiral staircase that we supply- for the simply reason it creates a stunning impression.  It is also very versatile with the treads supplied in any hardwood (oak and beech being the most popular) and the riser and going custom made for each project.

This particular spiral staircase was supplied to a customer in Poole to provide access to a new basement conversion.  Passage of light was the key so open risers were a must!   To comply to the 100mm sphere rule we included subtle 8mm thick acrylic riser pieces to reduce the gap without affecting the light passing through.  What is becoming extremely popular with the model 71 spiral staircase is to have curved acrylic or glass panels wrapping around the spiral instead of spindles.  This transforms to the spiral and again maximises the passage of light.

This spiral staircase was supplied with beech tread with three non slip groves and brushed stainless steel newels and centre column .  Overall diameter 1500mm diameter (ensuring a 600mm clear tread width for regulations) and a floor to floor height of 2800mm with 14 risers.  Also supplied was 3m of matching landing balustrade to complete the stunning addition to the build.

If you could like more information of the model 71 spiral staircase – please get in touch.  We have a showroom in Romsey (Hampshire) and you can email any plans to info@completestairsystems.co.uk or call 01794 522444 for a chat.

Filed under: Spiral Stair, Spiral Staircase, Staircase by Derrick
No Comments »

27th September 2012

The new staircase showroom in our new location in Romsey is coming on but still a bit of work to do.  Offices have been up and running for a couple of months and we plan to have fully finished the showroom by the end of November.

Reception area getting there...

This week we had a 100m square wall plastered and painted and next week the glass balustrade around the arke stair show area on the mezzanine level.

Arke stairs and Fakro windows in position

The week after we fit the main showroom spiral then the flooring will go down.  Will obviously post some pictures when complete!

Office - where the action takes place!

This will be a stunning staircase showroom (promise)

Until then we are getting into twitter and facebook in a big way with all our product ranges – be sure to ‘like’ and ‘follow’ us to keep up-to-date.  I do believe we also have pinterest and google plus accounts  – no idea why we need so many  – I’m personally a bit out of touch with all this social media stuff!

Fakro Blinds twitter -  https://twitter.com/FakroBlinds

Fakro Blinds facebook – http://www.facebook.com/pages/Fakro-Blinds/172318942799110

Kit Stairs twitter – https://twitter.com/Kitstairsystems

Kit Stairs facebook -http://www.facebook.com/pages/Kit-Stair-Systems/174567092582485

Fakro Loft Ladders twitter- https://twitter.com/LoftLaddersShop

Fakro loft ladders facebook- http://www.facebook.com/LoftLaddersShop

Filed under: Staircase Showroom by Derrick
No Comments »

17th September 2011

So busy at present – forgot to mention we will be at the GRAND DESIGNS LIVE show in Birmingham (NEC) in October.  The show runs from 7th-9th October which is a Friday / Saturday/Sunday stint.  We have stand B652 and will have a couple of displays models on show, namely the WF staircase and the Model 500 staircase.  Both stunning modern, light and open designs in timber and glass.  Obviously we will be there to discuss your stair requirements with tips and advice face to face.

Just for you we have 10 free tickets to give away.  The normal advanced booking cost is £14 with tickets £18 on the door.  These free tickets will be dispatched on a first-come-first-served basis so please email info@completestairsystems.co.uk or phone – 01794 522444 to make a claim.

If you would like to discuss a specfic project at the show - please email us plans in advance so we can have a look beforehand.

See you there!!!

…………………………………………………….

Follow @StunningStairs

Filed under: Grand Designs Live, kit spiral staircase, kit staircases, Modern Staircase, Oak Staircase, Spiral Stair, Spiral Staircase, Staircase, Timber Staircase by Derrick
No Comments »

2nd October 2010

Spiral Staircase supplied for a loft conversion in Chatham, Kent.

Our client selected the model 71 system which is a bespoke model. The rotation had to be made to suit the opening and surroundings.

This spiral was constructed with solid oak treads and brushed stainless steel spindles and centre column.  To comply with the 100mm gap rule, matching stainless steel riser bars were provided to reduce the gap between the treads.  The stair was provided with a couple of metres of matching landing balustrade running horizontally across the void. Being bespoke, the system can have stainless steel newels posts (top and bottom – instead of timber as shown here) the handrail can be stainless steel and the timber can be beech, oak, maple, birch, ash and a few more to boot – please call to check.

This spiral was for a loft conversion but the model 71 system is supplied in diameters large enough for a main domestic staircase – up to 2m in diameter! With the relevant clear tread width, centre, outer and inner going dims and spindle / riser gaps etc etc to satisfy BS5395 – category B.

 You can see more examples of this system using the links below.

Model 71 Spiral Staircase - Preston

Model 71 Spiral Staircases – Yorkshire

Model 71 Spiral Staircase – Treorchy

Model 71 Spiral Staircase – Manchester

To price – please let know the floor to floor height, the diameter you would like and the type of timber for the treads.

Filed under: Staircase by Mark
3 Comments »

Whilst our main site – www.completestairsystems.co.uk shows the full range of our staircases, we have set up a new website dedicated to our Kit staircases.  Please have a look at www.kitstairsystems.co.uk.  It has been built with the user in mind with very simple navigation and large pictures.  Prices are shown along with various downloads to help.

PRODUCTS displayed focus on the ARKE range featuring -

Kit Spiral Staircase KLAN

Kit Spiral Staircase CIVIK

Kit Spiral Staircase CIVIK ZINK

Space Saving Staircase KARINA

Space Saving Staircase KYA

Versatile Staircase KOMODA

Versatile Staircase KOMPACT

Kit Spiral Staircase KLOE

Filed under: Staircase by Derrick
No Comments »

Some stunning pictures of a bespoke spiral staircase supplied to a customer in Chichester.

This model has ‘chunky’ treads produced in walnut which box in the steel tread support.  Our customer opted for simply powder coated steel spindles and handrail which was continued around the opening upstairs.  Also supplied was a matching Walnut apron and Walnut floor rail for the landing balustrade.

This is a domestic spiral staircase providing access to one room.  It was 1600mm diameter and spanning a floor to floor height of 2560mm.

This spiral staircase is bespoke and therefore can be produced with any type of timber treads, the centre column can be powder coated any colour and the balustrade can be stainless steel instead.  Anything else – please ask!!!

You can view similar spiral staircases below, all manufacturered in the same structure -

http://www.completestairsystems.co.uk/ph_manchester.html

http://www.completestairsystems.co.uk/ph_penn.html

http://www.completestairsystems.co.uk/ph_essex.html

http://www.completestairsystems.co.uk/ph_perthshire.html



Filed under: Staircase by Derrick
1 Comment »

As we have been neglecting our news section for a little while we have built up a back log of recently completed staircase pictures to display.  From now on we will try to put up at least one a week.



Starting with this model 71 spiral which was installed in Yorkshire at the end of last year.  The customer was renovating an annex and required access to a mezzanine level in the roof.  A spiral was the only real option  as the exit point upstairs had to be directly under the apex of the roof.

The diameter of this model was 1600mm and it was spanning a floor to floor height of just over 2600mm.  The model 71 spiral always has a stainless centre column and spindles and on this occasion our customer selected beechwood treads which were stained ‘walnut’ in the factory.  Along with the spiral, 4.5m of matching landing balustrade was supplied for installation across the front of the mezz deck.

The model 71 is a bespoke spiral staircase.  It is available in diameters up to 2.4m and can be manufactured with a variety of timber treads – Oak, Ash, Maple, Beech and Larch. The newel posts and handrail are either timber to match the treads or stainless steel (click to view picture of this option).

Filed under: Staircase by Derrick
No Comments »

It has been a few weeks now since the show in Birmingham but just thought I would post some comments.
Although we had a very small stand in an ‘on paper’ bad position it was pretty succesful. We were situated near the toilets / food hall and the seminar theatres so got a fair amount of passing trade. Although we signed up too late to get into the showguide we had plenty of interest and have spent the last two weeks quoting solidly.
We do love talking about staircases and we did just that for four whole days!!!

Filed under: Staircase by Derrick
No Comments »

Some pictures we have just received from a model 76 supplied for a project in Maidstone, Kent.
Spiral staircase with acrylic treads and stainless steel balustrade creating a stunning centre piece with an open feel. The balustrade consists of several horizontal 10mm stainless bars which wrap around the circumference of the spiral emphasising the swoop of the flight.



  Some useful links on this spiral model

Model 76 web page
Different case study on the model
Product sheet on the model 76 spiral Staircase
Plus some other modern spirals in the same range
Model 71
Model 77
Model 74
Model 40
For a price we need to know your floor to floor height and diameter.  For help have a look at the Information page or call the office on 01794 522444.

Filed under: Staircase by Derrick
1 Comment »

Earlier this year we secured the contract to supply a large bespoke spiral staircase as part of a church hall renovation near Winchester in Hampshire.  It was to become a new domestic dwelling with a large spiral stair rising from the modern kitchen to the upper level.

We now have some pictures -

spiral Staircase with Walnut treads



This model has Walnut treads and an external stringer wrapping around the circumference emphasizing the swoop of the spiral.

spiral staircase with external stringer

spiral staircase with stainless steel balustrade

This spiral staircase was custom made for our client but is from our bespoke range of spirals which are all based on the same ‘structure’ then personalised with types of treads, balustrade, height, diameter and colour.

You can see further examples at the bottom of this post-

http://www.completestairsystems.co.uk/ph_manchester.html

http://www.completestairsystems.co.uk/wb_london.html

http://www.completestairsystems.co.uk/ph_penn.html

http://www.completestairsystems.co.uk/ph_essex.html

As normal, to work out a price we need the floor to floor height and diameter.  Plus an idea of the type of treads and balustrade you would like.

Filed under: Staircase by Derrick
